Description

CPU

• Intel® Alder Lake-N Processors N97

Chipset

• MCP

BIOS

• AMI SPI 256 Mbit

Technology

• Single Channel DDR4 3200 MHz

Capacity

• 32GB

Socket

• 1 x 260-pin SO-DIMM

Controller

• Intel® UHD Graphics

HDMI

• HDMI 2.0b
• Max resolution up to 4096×2160@60Hz

DisplayPort

• DisplayPort 1.4a, DP++
• Max resolution up to 4096×2160@60Hz

MultiDisplay

• Triple-Display (Included 2 outputs from Type-C)

M.2/WLAN

• 1 x Wifi-Fi 6E 802.11ax + BT 5.2

Interface

• Realtek ALC256, High Definition Audio.

Controller/ Speed

• LAN1: Realtek RTL8125BG with 10/100/1000/2500 Mbps
• LAN2: Realtek RTL8125BG with 10/100/1000/2500 Mbps

Connector

• 2 x RJ-45

USB

• 1 x USB 3.2 Gen2 (Type-A)
• 2 x USB 3.2 Gen2 (Type-C, Supports DP1.4a display output)

Audio

• 1 (headphone & microphone jack)

HDMI

• 2 x HDMI 2.0b

Ethernet

• 2 x 2.5 Gigabit LAN

USB

• 2 x USB 3.2 Gen2 (Type-A)

DC Jack

• 1

TPM

• TPM 2.0 onboard IC

M.2

• 1 x M.2(KEY M, 2242/2260/2280) with PCIe Gen3 x1 and SATA3 for SSD
• *M.2 Key M 2280(Supported by bracket)

SATA

• 1 x SATA3.0 (6.0 Gb/s)

Output

• From Super I/O to drag RESETCON#

Interval

• 256 Segments, 0, 1, 2, …255sec

Input PWR

• 9V~19V DC-In Jack

Power On

• AT/ATX Supported
• – AT : Directly PWR on as power input ready
• – ATX : Press button to PWR on after power input ready

Operating Temp

• 0ºC ~ 40ºC

Storage Temp

• -40° C – 85° C

Operating Humidity

• 5% ~ 90%

Storage Humidity

• 5% ~ 90%

Mounting

• VESA mount

Dimensions (L x W x H)

• 117.5 x 110.0 x 47.85mm (4.63″ x 4.33″ x 1.88″)

Weight

• Net Weight:1.0Kg

OS Support

• Windows 10/11

Certifications

• CE, FCC

Packing List

• 1 x 19V/65W Power Adapter
• 1 x VESA mount bracket
