Description
Form Factor
- 2U rack server 300mm (11.8in) depth with 4x FHHL adapters; or 2U rack server 360mm (14.2in) depth with 4x FHFL adapters
Processor
- 1x 3rd Gen Intel® Xeon® Platinum processor, up to 36 cores, up to 225W TDP
Drive Bays
- Up to 6x 2.5-inch 7mm drives; Up to 6x NVMe drives supported; 2x M.2 boot drives (RAID 1)
Memory
- 10x DDR4 memory slots; Maximum 1TB using 8x 128GB 3DS RDIMMs; Supports up to 2x Intel® Optane™ Persistent Memory 200 Series modules (PMem)
Expansion Slots
- Up to 4x PCIe 4.0 slots, 1x OCP 3.0 slot
GPUs
- Up to 4x single-width GPUs or 2x double-width GPUs
Network Interface
- LOM adapter installed in the OCP 3.0 slot; PCIe adapters
Ports
- Front: 1x Power Button, 1x system locator, health with LED, 1x VGA, 2x USB 3.1, 1x Serial Port (optional), 1x RJ-45 1Gb for dedicated management, 1x system locator LED; Optional Wi-Fi (management)
HBA/RAID Support
- SW RAID standard; optional HW RAID or SAS HBA
Power
- Dual redundant power supplies AC (up to 1800W Platinum) or Dual redundant power supplies -48V DC 1100W
Systems Management
- Lenovo XClarity Controller
OS Support
- Microsoft, Red Hat,Ubuntu, CentOS, VMware. Visit lenovopress.com/osig for details.
Limited Warranty
- 3-year customer replaceable unit and onsite service, next business day 9×5; optional service upgrades
